Appendix B: FBV Foot Controllers
B•9
FBV Express MkII - Footswitch & Pedal Mappings
Footswitch
Label
POD HD
Function
7-Segment LED
Display
Footswitch
LED
Description
D
Selects Preset D
(ABCD Mode)
Displays “D” to
indicate selected
Preset
Lit when
selected
Loads Preset D of
current Bank
FS8 On/Off
(FS 5-8 Mode)
Displays current
Preset channel
Lit when
Block active
Toggles the “FS8”
assigned Amp/FX
Block
Tempo
Indicator
Indicates current
Tempo rate
Dot flashes at
Tempo rate
N/A This is an indicator
LED only
Pedal Toe
Switch
EXP 1/EXP 2
Pedal Mode
No change EXP 1 =
WAH lit
EXP 2 =
VOL lit
Toggles the Pedal
between EXP 1 and
EXP 2 modes
Toe Switch No change No change Assignable footswitch
Looper Mode Footswitch Mappings
When POD HD is placed in Looper Mode, the FBV footswitches change their mappings
to perform the following Looper functions. Please also see “Looper Mode” on page 8•1.
FBV Express MkII - Looper Mode Footswitch Mappings
Footswitch
Label
POD HD Looper
Function
Footswitch LED Description
A
Record/Overdub Lit when recording,
Flashes when
overdubbing
Immediately starts recording - Or, if
a loop is currently playing, overdubs
on top of the current loop
B
Play/Stop Lit when playing Toggles the recorded loop to play
and stop
C
Full/Half Speed Lit when half speed Toggles the loop playback and
recording between full and half
speed
D
Reverse/Forward Lit when selected Toggles loop playback and recording
between normal and reverse
