FX Models
7•13
Volume/Pan & Wah Models
The Volume/Pan and Wah sets of Models are primarily designed to be used with an
FBV Controller Pedal.* However, you can also assign the TWEAK Controller to any of
these FX models’ “Position” parameters and manually work the effect - see “Tweak Knob
Assignment” on page 3•6.
*When you add any Wah or Volume Model to your tone, the EXP 1 and EXP 2 Controllers
are automatically assigned! Please see “Expression Pedal Assignment” on page B•16 for
more information.
Volume/Pan Models - Parameter Reference Table
Model Parameter
Volume Volume Level
Pan Pan L-R Balance
Volume
Volume: Adjusts the signal level. 100% is unity gain. This parameter can be accessed via
the Multi-function knob at any time. With your TWEAK knob or FBV Pedal assigned to
control the Volume, you’ll see this Volume parameter visually adjust with the knob/pedal
as well.
