System Setup
2•5
• Global - Once the “Global” option is selected here, the other three Input options’
valuesonthisSetuppage(InputSources1and2,andGuitarIn-Z)areutilized
globally, regardless of their values that are saved with each individual preset. The
Input values you choose on this Setup page are then retained independently for
the Inputs Setup - Global option. When you change the Inputs Setup back to
“Preset,” the Input options’ values saved with each individual preset are once
again utilized.
Note: Saving a preset while this option is set to “Global” will write the current global
Inputs and Guitar In-Z values to the individual, saved preset.
Amp & FX Model - Guitar Input Impedance Ratings
Model Guitar Input Impedance
(Ohms)
Amps & Preamps
All Amp & Preamp Models 1M
Distortion FX
Screamer 230k
Color Drive 136k
Buzz Saw 230k
Facial Fuzz 22k
Jumbo Fuzz 90k
Fuzz Pi 22k
Octave Fuzz 230k
All Other Distortion Models 1M
Dynamics FX
All Dynamics Models 1M
Modulation FX
Dual Phaser 230k
U-Vibe 90k
Analog Choruis 22k
All Other Modulation Models 1M
