Amp/Preamp Models
To follow is a table showing the classic amplifiers upon which all our HD Amp/Preamp
Models are based.* For more details, please also check out the POD HD Model Gallery,
available from http://line6.com/support/manuals/.
POD HD Amp/Preamp Models
Amp/Preamp Model Based On...*
Amp Disabled When selected, no Amp Model is loaded
Blackface Double Normal ‘65 “Blackface” Fender® Twin Reverb®, Normal input channel
Blackface Double Vibrato ‘65 “Blackface” Fender® Twin Reverb®, Vibrato input channel
Hiway 100 Hiwatt® Custom 100
Super O ‘60s Supro® S6616
Gibtone 185 Gibson® EH-185
Tweed B-Man Normal ‘59 Fender® Tweed Bassman®, Normal input channel
Tweed B-Man Bright ‘59 Fender® Tweed Bassman®, Bright input channel
Blackface ‘Lux Normal Fender® “Blackface” Deluxe Reverb®, Normal input channel
Blackface ‘Lux Vibrato Fender® “Blackface” Deluxe Reverb®, Vibrato input channel
Divide 9/15 Divided By 13 9/15
PhD Motorway Dr. Z® Route 66
Class A-15 ‘61 “Fawn” Vox® AC-15
Class A-30 TB Vox® AC-30 “Top Boost”
Plexi Lead 100 Normal ‘59 Marshall® “Plexi” Super Lead 100, Normal input channel
Plexi Lead 100 Bright ‘59 Marshall® “Plexi” Super Lead 100, Bright input channel
Brit J-45 Normal ‘65 Marshall® JTM-45 MkII, Normal input channel
Brit J-45 Bright ‘65 Marshall® JTM-45 MkII, Bright input channel
Brit P-75 Normal Park 75, Normal input channel
Brit P-75 Bright Park 75, Bright input channel
Brit J-800 Marshall® JCM-800
Bomber Uber 2002 Bogner Uberschall
Treadplate Mesa/Boogie® Dual Rectifier®
Angel F-Ball Engl® Fireball 100
Line 6 Elektrik A face-melting Line 6 original
Flip Top Ampeg® B-15NF Portaflex® bass guitar amp
* All product names are trademarks of their respective owners, which are in no way associated or affiliated with Line 6. These product names and descriptions are provided for the sole purpose of identifying the specific products that were studied during Line 6’s sound model
development. Fender®, Twin Reverb®, Bassman® and Deluxe Reverb® are registered trademarks of Fender Musical Instruments Corporation. Vox® is a registered trademark of Vox R&D Limited. Marshall® is a registered trademark of Marshall Amplification Plc. Dr. Z®
is a registered trademark of Dr. Z Amps, Inc. Mesa/Boogie® and Dual Rectifier® are registered trademarks of Mesa/Boogie, Ltd. Engl® is a registered trademark of Beate Ausflug and Edmund Engl. Hiwatt® is a registered trademark of Fernandes Company, Ltd. Fane® is a
trademark of Fane International. Gibson® is a registered trademark of Gibson Guitar Corp. Supro® is a registered trademark of Zinky Electronics.
