USB Audio
9•7
B
Device Properties: Choose your POD HD device here to allow the Audio Input and
Audio Output options display its settings.
C
Audio Input & Output Options: If you’ve selected your POD HD in the Device
Properties, these settings will all refer to your POD HD device:
• You’ll see the Input and Output selectors both disabled, showing Master Stream for
each. POD HD includes one stereo “xed” Input (Record Send 1-2) and one xed
stereo Output (Out 1-2).
• The Source options are also disabled for POD HD.
• The Format selectors show you the Sample Rate* and Bit Depth that POD HD is
operating at for recording. The Bit Depth for POD HD is fixed at 24 bit.
*It is recommended that you do not use the Sample Rate selectors in this window to set the
sample rate when your audio software is running. Typically, your audio software will offer a
sample rate option within its own “Preferences” settings.
• The Input Volume Sliders offer level control for the Record Send signal fed to your
recording software. Note that the sliders offer 18dB of input gain at the highest
setting.
• The Output Volume Sliders offer stereo level control for your software’s audio
playback fed to POD HD.
