5.5.4. The Wheels
The two wheels on the left side of the keyboard serve very different purposes.
5.5.4.1. Pitch wheel
The Pitch wheel sends MIDI Pitch Bend messages. It can't be reassigned to transmit another
type of data, but you can choose whether it will affect Part 1, Part 2, or both.
5.5.4.2. Modulation wheel
The Modulation wheel normally sends MIDI CC# 1, but it can be reassigned to a different CC
number using the MIDI Control Center [p.62]. Whatever it is configured to transmit, its data
can be sent from Part 1, Part 2, or both.
5.5.5. The Pads
♪: If one of the two Chord Memory buttons next to the pads are selected, they will only send the
MIDI note data that has been stored with the chord for that pad.
Each of the 16 pads can be assigned to send one of the following types of data on any MIDI
channel or on the User channel:
• The MIDI note number of your choice (with velocity and polyphonic aftertouch)
• Switch between two particular values of any MIDI CC number (toggle or gate
operation)
• Send a MIDI Program change / Bank Select message
The pads can also be used to call up a different User preset than the one currently selected.
More than one pad can be set to do this, which gives you the option to go in different
directions during a live performance, for example.
♪: The MCC [p.62] can be used to specify a particular color for each pad. If you choose the color blue
to represent MIDI notes and the color green to represent Program Changes, for example, then you'll
know at a glance which pad does what, even on a darkened stage.
5.5.6. DAW Command / User buttons
The DAW Command buttons can be used as switches to send particular MIDI data when in
User mode. The commands they can send are:
• Two particular values of any MIDI CC number (toggle or gate operation)
• MIDI Program change / Bank Select messages
Each button can have its own setting. And as with every other programmable control, these
settings can be made from the front panel or by using the MIDI Control Center [p.62].
Arturia - User Manual KeyLab MkII - User mode 50
