Arturia KeyLab 88 MkII [66/89] Parameters in user edit mode
![Arturia KeyLab 88 MkII [66/89] Parameters in user edit mode](/views2/2009531/page66/bg42.png)
7.2.5. Parameters (in User Edit mode)
7.2.5.1. CV Pitch
Connector / User Edit mode name Parameter Range
Pitch Out / CV Pitch Mode Volt/Oct, Hz/Volt
BaseNote 0V [a] Full MIDI note range (default = C-2)
BaseNote 1V [a] Full MIDI note range (default = C 0)
Note Priority Low / High / Last
Bend range 1-24 semitones
Assign Part 1, Part 2
[a] These two settings are mutually exclusive
7.2.5.2. CV Gate
Connector / User Edit mode name Parameter Range
Gate Out / CV Gate Mode S-Trig, V-Trig (5V, 12V)
7.2.5.3. CV Mod Out 1
Connector / User Edit mode name Parameter Range
Mod 1 / CV Mod Out 1 Assign Any control (default: Velocity)
Volt range 1-10 V
7.2.5.4. CV Mod Out 2
Connector / User Edit mode name Parameter Range
Mod 2 / CV Mod Out 2 Assign Any control (default: Mod Wheel)
Volt range 1-10 V
61 Arturia - User Manual KeyLab MkII - CV / Gate / Mod connections
