8.8.3. Fader RPN / NRPN
The faders have the option to transmit Registered Parameter Numbers (RPN) or Non-
Registered Parameter Numbers (NRPN). These are numbers that can be used by various
manufacturers to allow their proprietary parameters to be controlled by external devices.
Refer to the documentation of the target instrument to see if it can respond appropriately to
these commands.
• Option: Specify whether the fader needs to transmit RPN or NRPN data.
• Channel: Select the MIDI channel output for the selected fader, between 1 to 16.
This can also be set to “User”, which will make the fader output the RPN/NRPN
data to the MIDI channel selected for the MIDI Ch button [p.64].
• RPN / NRPN LSB: Defines the RPN/NRPN value for Least Significant Byte that the
fader will send when activated. Click/drag the knob or enter a value between 0
and 127 in the field below.
• RPN / NRPN MSB: Defines the RPN/NRPN value for Most Significant Byte that the
fader will send when activated. Click/drag the knob or enter a value between 0
and 127 in the field below.
Arturia - User Manual KeyLab MkII - MIDI Control Center 72
