8.12.3. Pedal Switched Control

This option can be selected to use your pedal as a binary switch.

• Option: Choose between Gate and Toggle. Gate activates the pedal only when

pressed and deactivates it when released; Toggle activates the pedal when

pressed and deactivates it when it is pressed again.

• Channel: Select the MIDI channel output for the selected pedal, between 1 to 16.

This can also be set to “User”, which will make the pedal output to the MIDI

channel selected for the MIDI Ch button [p.64].

• CC Number: The selected pedal can be set to transmit any MIDI CC# between

0-127. Many MIDI CC numbers are named within the drop-down menu to identify

standard uses. For example, to use one of the pedals as a sustain pedal, set this

value to CC# 64.

• Off Value: When the pedal is released it doesn't have to return to a zero value,

although a zero value may be needed for some external devices or software

plug-ins to function properly. Click/drag the knob or enter a value in the field

below to set the minimum value the pedal will send when it is released.

• On Value: Click/drag the knob or enter a value in the field below to set the

maximum value the pedal will send when it is pressed.



♪: All 5 pedal inputs can detect the polarity of a foot switch when the KeyLab mkII is powered up. To

make sure this happens, set the desired pedal input to the Switched control mode. This is not a global

parameter, though, so if you want each User preset to be configured this way you will need to store this

setting separately in each User preset.

8.12.4. Pedal Program Change

This option lets you use any of the pedal inputs to send MIDI Program changes.

• Channel: Select the output MIDI channel for the selected pedal, between 1 to 16.

This can also be set to “User”, which will make the pedal transmit on the MIDI

channel selected for the MIDI Ch button [p.64].

• Program Number: Select the MIDI Program number the pedal will send when

activated. Click/drag the knob or enter a value between 0 and 127 in the field

below.

• Bank LSB: Defines the Bank Select value for Least Significant Byte (MIDI CC#

32) that the pedal will send when activated. Click/drag the knob or enter a value

between 0 and 127 in the field below. Not all devices respond to Bank LSB, so

consult the documentation of the hardware or software instrument you want to

control.

• Bank MSB: Defines the Bank Select value for Most Significant Byte (MIDI CC#

0) that the pedal will send when activated. Click/drag the knob or enter a value

between 0 and 127 in the field below. Not all devices respond to Bank MSB, so

consult the documentation of the hardware or software instrument you want to

control.
