8.3. Customize the Wheels



♪: Settings of

Part 2

and

Both

are only recommended when Split mode is active. That is the only time

that Part 2 is available from the keyboard.

8.3.1. Pitch Bend

The Pitch Bend wheel is reserved for that function; it can't be assigned to send any other

type of MIDI data. But you can select whether it will affect Part 1, Part 2, or both.

8.3.2. Modulation

• Mode: Select "Control" to view the rest of the parameters. Select "Off" and the

Modulation wheel will be disabled for both Part 1 and Part 2.

• Channel: Specify whether the Modulation wheel will affect Part 1, Part 2, or both.

• CC Number: The Modulation wheel sends MIDI CC# 1 by default, but it can be

configured to transmit any MIDI CC#.

• Min Value: Click/drag the knob or enter a value in the field below to set the

minimum value the Modulation wheel will send.

• Max Value: Click/drag the knob or enter a value in the field below to set the

maximum value the Modulation wheel will send.

8.4. Select the User Channel

There's a small, rectangular button between the wheels and the pads that is labeled MIDI

Ch. Click the graphic and you will be able to specify the User MIDI channel for the KeyLab

mkII.



♪: The MIDI Channel number selected for the MIDI Ch button will also change the MIDI Channel for

any control that has its MIDI Channel set to "User".
