STATUS UniOne CP 125 07410501 [11/72] Operation

OPERATION

• Select a suitable inner ange (3a) (20 or 22.2 mm) depending on the inner diameter of

the blade used. Install selected inner ange on the spindle like shown on the Fig. 4.

• Make sure the blade teeth and arrow on the blade (1) point in the same direction as the

arrow on the upper blade guard (6).

• Slide the new blade (1) through slot in the base plate (5) and mount it against the inner

blade ange (3a) on the shaft. Make sure the large diameter of the blade anges lay

ush against the blade (1).

• Tighten the outer blade ange (3). First tighten blade bolt (4) to nger tight. Engage

spindle lock button (21). Whilst depressing the spindle lock button (21), tighten blade

bolt (4) rmly with the blade hex key supplied with the machine.

• Before connecting the saw to a power source, ensure that:

- The spindle lock button (21) is released;

- The blade (1) rotates freely;

- The lower blade guard (20) operates correctly.

NOTE: Do not modify the blade spanner to elongate it, since it may lead to over tightening

of the blade bolt (4).

ADJUSTING THE CUTTING DEPTH

Loosen the depth adjustment lever (14). Hold the base plate (5) down with one hand and

raise or lower the saw by the back handle (8). Tighten depth adjust lever (14) at the desired

depth setting.

To obtain minimum splintering while operating, ensure that no more than one tooth

protrudes through the timber.

NOTE: During bevel cutting the depth set on scale (13) does not coincide with the real

depth value. In this case the depth should be measured from the tip of the tooth to the

edge of the slot in the base plate with a measuring tool.

DUST EXTRACTION

Use a vacuum cleaner during operation. Connect the vacuum cleaner to the dust extraction

tube (7) and switch on the vacuum cleaner prior to starting a cut.

ADJUSTING THE BEVEL

Vertical cutting

Set maximum cutting depth. Loosen bevel adjustment xing (24), set it to 0º on bevel scale

(23), retighten bevel adjustment xing (24) and check for 90º angle between the blade (1)

and bottom plane of the base plate (5) with a square.

Bevel cutting

The base plate (5) can be adjusted to 0°–45°. Loosen the bevel adjustment xing (24). Align

it to the desired angle on calibrated bevel scale (23). Then tighten bevel adjustment xing

(24).
