Diagrams 31_0688 FRONT SPRING STRUT Series K25 R1200 GS 131803 No Description 1 FRONT SPRING STRUT 2 BUSH 3 SPACER SLEEVE 4 FLAT WASHER 5 HEX NUT 6 FIT BOLT Supplement 10 5 M10X1 25 M10X50 Qty From Up To Part Number AT 1 2 31 42 7 659 619 31 42 2 311 994 31 42 7 665 662 07 11 9 936 401 07 11 9 900 291 31 42 7 686 733 1 1
