ENGLISH

Original instructions for use

• Risk of tripping over the electric cable. Always be aware

of the whereabouts of the electric cable so that it does not

get in the way of your feet or anything else moving about

in the area.

• The snow thrower may only be connected with a cable

that is approved for outdoor use.

• The electric cable with which the snow thrower is

connected must always be intact. It must never be used if

it displays signs of damage.

• The snow thrower must never be used if its plug, electric

cable or other electrical equipment is damaged.

• Repairs to the electrical equipment may only be carried

out by an authorised electrician.

• Never drive over the electric cable for the snow thrower

while working.

• If the electric cable for the snow thrower has been

damaged while working, the following instructions must

be followed:

A. Stop the motor.

B. Leave the site in the opposite direction from the

damaged point on the cable.

C. Disconnect the cable from the power socket.

• Stop the motor and disconnect the power supply:

A. If the driver leaves the machine.

B. If the auger housing or discharge chute is blocked and

must be cleaned.

C. Before beginning repairs or adjustments.

• Always make sure the rotating parts have stopped and all

the controls are disengaged before cleaning, repairing or

inspection.

• Never drive across a slope. Move from the top down, and

from the bottom to the top. Be careful when changing

direction on a slope. Avoid steep slopes.

• Never operate the machine with insufficient protection or

without the safety devices in place.

• Existing safety devices must not be disconnected or

disengaged.

• Never use the snow thrower near enclosures, cars,

windowpanes, slopes etc. without properly setting the

discharge chute deflector.

• Always keep children away from areas to be cleared. Get

another adult to keep the children under supervision.

• Do not overload the machine by driving it too fast.

• Take care when reversing. Look behind you before and

during reversing to check for any obstacles.

• Never point the discharge chute towards bystanders. Do

not allow anyone to stand in front of the machine.

• Only use accessories that are approved by the machine’s

manufacturer.

• Never drive the snow thrower in bad visibility or without

satisfactory lighting.

• Always ensure you have a good balance and a tight grip

on the handle.

2.4 MAINTENANCE AND STORAGE

• Tighten all nuts and screws so that the machine is in safe

working condition.

• Never flush the machine with water. It will make damage

to the electrical equipment and risk of electrical shocks.

• Check all electrical equipment before use. The snow

thrower must never be used if its insulatings, fittings or

other electrical equipment is damaged.

• Always use genuine spare parts. Non-genuine spare parts

can entail a risk of injury, even if they fit the machine.

• Before a long storage, check the instructions for

recommendations.

• Replace damaged warning and instruction stickers.

• Let the engine run a couple of minutes with the auger

connected after use. This prevents the auger from

freezing solid.

3 ASSEMBLY

3.1 UNPACKING

1. Open the box carefully.

2. Take care of any documentation in the box, for example

these instructions.

3. Lift the snow thrower from the box.

4. Cut the tie straps and remove all protecting plastic from

the machine.

5. Dispose of the box and packaging according to local

regulations.

3.2 ASSEMBLY

1. Assemble the snow thrower as follows.

2. See fig. 2. Align the square dog at the shank against the

recess in the handle.

3. Se fig. 3. Slide the shank and the handle together until the

tap locks in the shank.

4. See fig. 4. Screw on, and tighten the big plastic nut.

5. See fig. 5. Assemble the black plastic sleeve on the shank

until the tap locks in the shank hole.

6. See fig. 6. Align the shank against the snow thrower so

the sleeve groove fits against the hole bar.

7. See fig. 7. Slide the shank into the snow thrower and

assemble the two screws with nuts. Tighten with a Philips

screwdriver.

4 DESCRIPTION

The snow thrower is intended for small snow cleaning works

quite close to houses with stationary 230 VAC electric net.

The snow thrower controls are shown in fig. 1 and described

below.

Pos Denomination Description

A Starting lockout Prevents the start lever to be

activated unintentionally.

B Start lever Starts the engine. The lever can be

activated if the starting lockout A is

depressed.

C Connecting device For connection of current.

D Cable support For supporting the connection cable.

E Lock handle For securing the shank handle.

F Handle

G Shank The length can be adjusted.

H Lock handle For securing the shank.

J Auger housing

K Auger
