X-6 EP1085

Terms and Symbols Used

 Lengthwise

When theoriginalorcopyhasa“length”

longer than its “width,” we call it

“lengthwise” and use symbol “L” or

““.

 Crosswise

When theoriginalorcopyhasa“length”

shorter than its “width,” we call it

“crosswise” and use symbol “C” or “ ”
