Konica Minolta EP1085 [21/115] Automatic document feeder af 5

Getting to Know Your Copier

EP1085 2-5

Automatic Document Feeder AF-5

Pcs. Specification Description

1 Document Feed Tray

Extender

Pull out when loading large-size originals, see page 3-7.

2 Document Feed Tray Load the originals face up on this tray, see page 3-7.

3 Document Guide Plate Slide theplate as necessarytothesizeofthe originals, see

page 3-7.

4 Document Exit Tray Receives originals that are automatically ejected from

the Automatic Document Feeder.
