Making Copies
3-20 EP1085
Selecting the Finishing Mode
Press the Finishing Mode Select Key to
select the desired mode.
If the Sort Mode is selected, the Sort
Indicator lights.
NOTES
è The Sort Mode cannot be selected unless the copier is equipped with
the10-BinSorter.
è If the Sort Indicator is not lit up, the Non-Sort Mode is selected.
è The capacity of each Sorter Bin is
25 copies in Sort-Mode.
è If this capacity is exceeded, the
Remove Copies Indicator blinks on
the Monitor Display and the Start
Key turns orange, inhibiting the
initiation of a new copy cycle.
Useful Tip
The copier has been factory-set to automatically select Non-Sort.
Also, the copier automatically switches between the Sort and Non-Sort
mode depending on the number of originals loaded in the Automatic
Document Feeder. The User’s Choice can, however, be used to
change this default setting using the User’s Choice, see page 4-9 and
seepage4-11.
Sort
1142O098CC
1142O051AA
