Safety Notes
1
EP1085 1-5
NOTE
Locate the Copier in a Well Ventilated Room
è A negligible amount of ozone is generated during normal operation of
this copier. An unpleasant odor may, however, be created in poorly
ventilated rooms during extensive copier operations. For a
comfortable, healthy, and safe operating environment, it is
recommended that the room be well ventilated.
Placer le copieur dans une pièce largement ventilée
è Une quantité d’ozone négligable est dégagée pendant le
fonctionnement du copieur quand celui-ci est utilisé normalement.
Cependant, une odeur désagréable peut être ressentie dans les
pièces dont l’aération est insuffisante et lorsque une utilisation
prolongéedu copieuresteffectuée.Pouravoirlacertitude detravailler
dans un environnement réunissant des conditions de confort, santè et
de sécurité, il est préférable de bien aérer la pièce ou se trouve le
copieur.
Care of Copier Supplies
Use the following precautions when handling the copier supplies (toner,
paper, etc.).
Store the paper, toner, and other supplies in a place free from direct
sunlight and away from any heating apparatus. Keep them in a dry,
clean environment.
Store paper, which has been removed from its wrapper but not loaded
into the drawer, in a sealed plastic bag in a cool, dark place.
Use the correct toner for the exclusive use by the copier. The
applicable copier model name is indicated on the Toner Bottle.
Keep supplies out of the reach of children.
If your hands become soiled with toner, wash them with soap and
water immediately.
Moving
If you need to transport the copier over a long distance, consult your
Technical Representative.
