DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
157
enable gvrp
Purpose
Used to enable GVRP on the Switch.
Syntax
enable gvrp
Description
This command, along with disable gvrp below, is used to enable and
disable GVRP on the Switch, without changing the GVRP configuration
on the Switch.
Parameters
None.
Restrictions
Only Administrator level, Operator level or Power User level users can
issue this command.
Example usage:
To enable the generic VLAN Registration Protocol (GVRP):
DES-1228/ME:5#enable gvrp
Command: enable gvrp
Success.
DES-1228/ME:5#
disable gvrp
Purpose
Used to disable GVRP on the Switch.
Syntax
disable gvrp
Description
This command, along with enable gvrp, is used to enable and disable
GVRP on the Switch, without changing the GVRP configuration on
the Switch.
Parameters
None.
Restrictions
Only Administrator level, Operator level or Power User level users
can issue this command.
Example usage:
To disable the Generic VLAN Registration Protocol (GVRP):
DES-1228/ME:5#disable gvrp
Command: disable gvrp
Success.
DES-1228/ME:5#
