DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
197
config 802.1x capability ports
Purpose
Used to configure the 802.1X capability of a range of ports on the
Switch.
Syntax
config 802.1x capability ports [<portlist> | all] [authenticator | none]
Description
This command has two capabilities that can be set for each port,
authenticator and none.
Parameters
<portlist> − Specifies a port or range of ports to be configured.
all − Specifies all of the ports on the Switch.
authenticator − A user must pass the authentication process to gain
access to the network.
none − The port is not controlled by the 802.1X functions.
Restrictions
Only Administrator level, Operator level or Power User level users
can issue this command.
Example usage:
To configure 802.1X capability on ports 1 to 10:
DES-1228/ME:5#config 802.1x capability ports 1–10 authenticator
Command: config 802.1x capability ports 1–10 authenticator
Success.
DES-1228/ME:5#
