D-Link des-1228/me/b1 [388/413] Debug software commands
![D-Link des-1228/me/b1 [388/413] Debug software commands](/views2/1166101/page388/bg184.png)
DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
384
51
DEBUG SOFTWARE COMMANDS
The Debug Software commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table.
debug error_log [dump | clear | upload_toTFTP [<ipaddr> ] <path_filename
64>]
debug config
error_reboot
[enable | disable]
debug show error_reboot
state
debug error_log
Purpose
Use this command to dump, clear or upload the software error log to a
TFTP server.
Syntax
debug error_log [dump | clear | upload_toTFTP [<ipaddr> ]
<path_filename 64>]
Description
Dump, clear or upload the debug log to a TFTP server. The “error log”
here refers to the software error log stored in NVRAM.
Parameters
dump − Display the debug message of the debug log.
clear − Clear the debug log.
upload_toTFTP − Upload the debug log to a TFTP server specified by
IP address.
<ipaddr> − Specifies the IPv4 address of the TFTP server.
<path_filename 64> − The pathname specifies the DOS pathname on
the TFTP server. It can be a relative pathname or an absolute
pathname.
Restrictions
Only Administrator-level users can issue this command.
Example usage:
To dump the error log:
