![D-Link des-1228/me/b1 [169/413] Basic ip commands](/views2/1166101/page169/bga9.png)
DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
165
18
BASIC IP COMMANDS
The Basic IP interface commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table:
Command Parameters
config ipif [System] [{ ipaddress <network_address> | vlan <vlan_name
32> | state [enable|disable]} | bootp | dhcp | dhcp_option12
[hostname <hostname 63
>| clear_hostname | state
[enable|disable]] | ipv6 ipv6address <ipv6networkaddr>]
show ipif
enable autoconfig*
disable autoconfig
delete ipif [System] [ipv6adress <ipv6networkaddr>]
enable
ipif_ipv6_link_local_auto
[System]
disable
ipif_ipv6_link_local_auto
[System]
show
ipif_ipv6_link_local_auto
Each command is listed, in detail, in the following sections:
*See Switch Utility Commands for descriptions of all autoconfig commands.
