![D-Link des-1228/me/b1 [338/413] Ommands](/views2/1166101/page338/bg152.png)
DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
334
40
DOS PREVENTION COMMANDS
The DoS Prevention commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table:
Command Parameters
config dos_prevention
dos_type
[ {land_attack | blat_attack | smurf_attack | tcp_null_scan |
tcp_xmascan | tcp_synfin | tcp_syn_srcport_less_1024} (1) |
all] {action [ drop | mirror <port> {priority <value 0-7> |
rx_rate [ no_limit | <value 64-1024000> ] } ] | enable |
disable ]} (1)
show dos_prevention {land_attack | blat_attack | smurf_attack | tcp_null_scan |
tcp_xmascan | tcp_synfin | tcp_syn_srcport_less_1024}
clear dos_prevention
counters
{land_attack | blat_attack | smurf_attack | tcp_null_scan |
tcp_xmascan | tcp_synfin | tcp_syn_srcport_less_1024}
enable dos_prevention
trap_log
disable dos_prevention
trap_log
Each command is listed, in detail, in the following sections:
