DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
250
Example usage:
To disable MAC notification without changing basic configuration:
DES-1228/ME:5#disable mac_notification
Command: disable mac_notification
Success.
DES-1228/ME:5#
config mac_notification
Purpose
Used to configure MAC address notification.
Syntax
config mac_notification {interval <int 1-2147483647> | historysize
<int 1-500>} (1)
Description
This command is used to monitor MAC addresses learned and
entered into the FDB.
Parameters
interval <int 1-2147483647> − The time in seconds between
notifications. The user may choose an interval between 1 and
2147483647 seconds.
historysize <1-500> − The maximum number of entries listed in the
history log used for notification.
Restrictions
Only Administrator level, Operator level or Power User level users
can issue this command.
Example usage:
To configure the Switch’s MAC address table notification global settings:
DES-1228/ME:5#config mac_notification interval 1 historysize 500
Command: config mac_notification interval 1 historysize 500
Success.
DES-1228/ME:5#
config mac_notification ports
Purpose
Used to configure MAC address notification status settings.
Syntax
config mac_notification ports [<portlist> | all] [enable | disable]
Description
This command is used to monitor MAC addresses learned and entered
into the FDB.
Parameters
<portlist> − Specifies a port or range of ports to be configured.
all – Entering this command will set all ports on the system.
[enable | disable] – These commands will enable or disable MAC
address table notification on the Switch.
Restrictions
Only Administrator level, Operator level or Power User level users can
issue this command.
