DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
380
50
IPV6 NEIGHBOUR DISCOVERY COMMANDS
The IPv6 Neighbor Discovery commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters)
in the following table.
create ipv6
neighbor_cache ipif
<ipif_name 12> <ipv6addr> <macaddr>
delete ipv6
neighbor_cache ipif
[<ipif_name 12> | all] [<ipv6addr> | static |dynamic |all]
show ipv6
neighbor_cache ipif
[<ipif_name 12> | all] [ipv6address <ipv6addr> | static
|dynamic |all]
show ipv6 nd {ipif <ipif_name 12>}
config ipv6 nd ns ipif <ipif name 12> retrans_time <uint 0–4294967295>
create ipv6 neighbor_cache ipif
Purpose
Used to add a static neighbor to an IPv6 interface.
Syntax
create ipv6 neighbor_cache ipif <ipif_name 12> <ipv6addr>
<macaddr>
Description
This command is used to add a static neighbor to an IPv6 interface.
Parameters
<ipif_name> − The interface’s name.
<ipv6addr> − The address of the neighbor.
<macaddr> − The MAC address of the neighbor.
Restrictions
Only Administrator level, Operator level or Power User level users can
issue this command.
Example usage:
To create a static neighbor cache entry:
DES-1228/ME:5
#create ipv6 neighbor_cache ipif System 3ffc::1
00:01:02:03:04:05
Command: create ipv6 neighbor_cache ipif System 3ffc::1 00:01:02:03:04:05
Success.
DES-1228/ME:5#
delete ipv6 neighbor_cache ipif
Purpose
Used to delete an IPv6 neighbor from the interface neighbor address
cache.
Syntax
delete ipv6 neighbor_cache ipif [<ipif_name 12> | all] [<ipv6addr> | static
| dynamic | all]
Description
This command is used to delete a neighbor cache entry or static
neighbor cache entries from the address cache or all address cache
entries on this ipif. Both static and dynamic entry can be deleted.
Parameters
<ipif_name> − The IPv6 interface’s name.
<ipv6addr> − The address of the neighbor.
