DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
60
Example usage:
To display the currently configured SNMP groups on the Switch:
DES-1228/ME:5#show snmp groups
Command: show snmp groups
Vacm Access Table Settings
Group Name : dlink
ReadView Name : dlinkview
WriteView Name : dlinkview
Notify View Name : dlinkview
Securiy Model : SNMPv3
Securiy Level : NoAuthNoPriv
Group Name : public
ReadView Name : CommunityView
WriteView Name :
Notify View Name : CommunityView
Securiy Model : SNMPv1
Securiy Level : NoAuthNoPriv
Group Name : public
ReadView Name : CommunityView
WriteView Name :
Notify View Name : CommunityView
Securiy Model : SNMPv2
Securiy Level : NoAuthNoPriv
CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a All
