DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
90
show error ports
Purpose
Used to display the error statistics for a range of ports.
Syntax
show error ports <portlist>
Description
This command is used to display all of the packet error statistics
collected and logged by the Switch for a given port list.
Parameters
<portlist> − Specifies a port or range of ports to be displayed.
Restrictions
None.
Example usage:
To display the errors of the port 3:
DES-1228/ME:5#show error ports 1
Command: show error ports 1
Port Number : 1
RX Frames TX Frames
--------- ---------
CRC Error 0 Excessive Deferral 0
Undersize 0 CRC Error 0
Oversize 0 Late Collision 0
Port Number : 1 Excessive Collision 0
RX Frames TX Frames
--------- ---------
CRC Error 0 Excessive Deferral 0
Undersize 0 CRC Error 0
Oversize 0 Late Collision 0
Fragment 0 Excessive Collision 0
Jabber 0 Single Collision 0
Drop Pkts - Collision 0
CTRL+C ESC q Quit SPACE n Next Page p Previous Page r Refresh
