DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
405
Service
BPDU
Protecction
BPDU attack happened.
Port <portNum> enter BPDU under protection state (mode: drop /
block / shutdown)
Informational
BPDU attack automatically
recover
Port <portNum> recover from BPDU under protection state
automatically
Informational
BPDU attack manually recover
Port <portNum> recover from BPDU under protection state
manually
Informational
DHCP Server
Screening
Detected untrusted DHCP
server IP address.
Detected untrusted DHCP server(IP: <ipaddr>, Informational
