DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
354
43
FLOW METER COMMANDS
The Flow Meter commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table:
Command Parameters
config flow_meter
profile_id
<value 1-256> access_id < access_id >[[ rate <value 64-
1024000> burst_size <value 0-1016> rate_exceed
[drop_packet|remark_dscp <value 0-63>]] |delete]
show flow_meter {profile_id <value 1-256> {access_id <access_id>}}
Each command is listed, in detail, in the following sections.
