DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
72
Example Usage:
To disable RMON:
DES-1228/ME:5#disable rmon
Command: disable rmon
Success.
DES-1228/ME:5#
config snmp coldstart_traps
Purpose
Used to configure the trap for coldstart event.
Syntax
config snmp coldstart_traps [enable | disable]
Description
This command is used to configure the trap state for coldstart event
Parameters
enable – enable trap of coldstart event.
disable – disable trap of coldstart event.
Restrictions
Only Administrator level users can issue this command.
Example usage:
To enable the trap for coldstart events:
DES-1228/ME:5# config snmp coldstart_traps enable
Command: config snmp coldstart_traps enable
Success.
DES-1228/ME:5#
config snmp warmstart_traps
Purpose
Used to configure the trap for warmstart event.
Syntax
config snmp warmstart_traps [enable | disable]
Description
This command is used to configure the trap state for warmstart event
Parameters
enable – enable trap of warmstart event.
disable – disable trap of warmstart event.
Restrictions
Only Administrator level users can issue this command.
Example usage:
To enable the trap for warmstart events:
DES-1228/ME:5# config snmp warmstart_traps enable
Command: config snmp warmstart_traps enable
Success.
DES-1228/ME:5#
