DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
295
Example usage:
To display the DHCP local relay function:
DES-1228/ME:5#show dhcp_local_relay
Command: show dhcp_local_relay
DHCP/BOOTP Local Relay Status : Enabled
DHCP/BOOTP Local Relay VID LIST : 1
DHCP Relay Agent Information Option 82 Remote ID : "access1"
DES-1228/ME:5#
show dhcp_local_relay option_82 ports
Purpose
Used to display the current DHCP Local Relay port configuration.
Syntax
show dhcp_local_relay option_82 ports { <portlist> }
Description
This command is used to display the current DHCP Local Relay port
configuration.
Parameters
portlist – Specifies a range of ports to display.
Restrictions
None.
Example usage:
To display DHCP local relay option 82 policy of port 1-8:
DES-1228/ME:5#show dhcp_local_relay option_82 ports 1-8
Command: show dhcp_local_relay option_82 ports 1-8
Port Option 82
Policy
---- ---------
1 replace
2 drop
3 keep
4 keep
5 keep
6 keep
7 keep
8 keep
DES-1228/ME:5#
