DES-1228/ME Metro Ethernet Managed Switch CLI Reference Guide
42
config port_security ports
Purpose
Used to configure port security settings.
Syntax
config port_security ports [<auth_portlist> | all ] {admin_state [enable | disable] |
max_learning_addr <max_lock_no 0-64> | lock_address_mode [ DeleteOnTimeout |
DeleteOnReset | Permanent]} (1)
Description
This command is used to configure the port security feature. Only the ports listed in the
<auth_portlist> are affected.
Parameters
<auth_portlist> − Specifies a port or range of ports to be configured.
all − Configure port security for all ports on the Switch.
admin_state [enable | disable] − Enable or disable port security for the listed ports.
max_learning_addr <max_lock_no 0-64> − Use this to limit the number of MAC addresses
dynamically listed in the FDB for the ports.
lock_address_mode [DeleteOnTimout | DeleteOnReset | Permanent] − Indicates the method
of locking addresses. The user has three choices:
DeleteOnTimeout – The locked addresses will age out after the aging timer expires (Aging
Time is set using the FDB command).
DeleteOnReset – The locked addresses will not age out until the Switch has been reset.
Permanent – The locked addresses will not age out.
Restrictions
Only Administrator level, Operator level or Power User level users can issue this command.
Example usage:
To configure the port security:
DES-1228/ME:5#config port_security ports 1-
5 admin_state enable
max_learning_addr 5 lock_address_mode DeleteOnReset
Command: config port_security ports 1-
5 admin_state enable
max_learning_addr 5 lock_address_mode DeleteOnReset
Success.
DES-1228/ME:5#
