8
English
6. Do not use the battery for a purpose other than
those specified.
7. If the battery charging fails to complete even when
a specified recharging time has elapsed,
immediately stop further recharging.
8. Do not put or subject the battery to high
temperatures or high pressure such as into a
microwave oven, dryer, or high pressure container.
9. Keep away from fire immediately when leakage or
foul odor are detected.
10. Do not use in a location where strong static
electricity generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears
abnormal during use, recharging or storage,
immediately remove it from the equipment or
battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your
eyes, do not rub your eyes and wash them well
with fresh clean water such as tap water and contact
a doctor immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well
with clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return it
to your supplier or vendor.
SPECIFICATIONS
POWER TOOL
STANDARD ACCESSORIES
1 Plus driver bit (No. 2 × 50L) ............. 1
WH10DL 2 Battery (BCL1015) ............................. 2
(2LCSK) 3 Charger
(UC10SFL) ................................
1
4 Plastic case ........................................ 1
WH10DL Without plus driver bit, battery,
(NN) charger and plastic case.
Standard accessories are subject to change without
notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery (BCL1015)
Optional accessories are subject to change without notice.
No-load speed 0-2300 min
–1
Capacity (Ordinary bolt) M5 – M12
Tightening torque (Maximum) 105 N·m
Rechargeable battery BCL1015: Li-ion DC 10.8 V / 12 V Peak (1.5 Ah 3 cells)
Weight 0.9 kg
APPLICATIONS
䡬 Driving and removing of machine screws, wood
screws, tapping screws, etc.
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latch to
remove the battery (see Figs. 1 and 2).
CAUTION:
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger power cord to the receptacle
2. Insert the battery in the charger
Position the battery so that the nameplate faces
toward the nameplate of the charger and press in the
battery until it comes into contact with the bottom
plate (See Fig. 3).
Inserting the battery will turn on the charger (the
pilot lamp lights up).
CAUTION
If the pilot lamp does not light up, pull out the
power cord from the receptacle and check the
battery mounting condition.
The pilot lamp goes off to indicate that the battery is
fully charged.
CHARGER
Model UC10SFL
Charging voltage 10.8 V
Weight 0.35 kg
01Eng_WH10DL_EE 6/13/09, 10:58 AM8
