Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-55
Error Troubleshooting
ADF Cover Open
The ADF cover is open.
Applicable Error
• 005-301: ADF Cover Open
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.3.3
■ ADF Assembly, PL8.1.2
■ “Map 3 - IP Board” on page 7-8
■ “Scanner” on page 7-28
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the ADF Cover completely closed? Go to Step 3. Close the ADF
cover and go
to Step 2.
2 Does the error persist? Go to Step 3. Complete.
3 Is the ADF Cover damaged? Replace the
ADF Cover
(page 4-113).
Go to Step 4.
Go to Step 5.
4 Does the error persist? Go to Step 5. Complete.
5 Reseat P/J1, P/J6, and P/J16 on the
IP Board.
Does the error persist?
Go to Step 6. Complete.
6 Replace the ADF (page 4-111).
Does the error persist?
Replace the IP
Board
(page 4-103).
Complete.
