Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-87
Error Troubleshooting
Fax Job Failure
The FAX memory is full.
Applicable Error
• 033-787: Fax Job Failure
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.3.3
■ MCU Board, PL7.1.3
■ Fax Board, PL7.3.4
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat all connectors on the fax
Board, IP Board and the MCU Board.
Does the error persist?
Go to Step 2. Complete.
2 Replace the Fax Board (page 4-105).
Does the error persist?
Go to Step 3. Complete.
3 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 4. Complete.
4 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
