Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only A-7
Reference
Test Print
Two test prints are available, Test pattern ASIC and LPH K. Select the pattern from
the menu and click the print button.
Parameter
This function reads/writes the parameters in the table. Click Apply new settings or
Restart printer to apply new settings button after the setting is completed to
change the value in NVM.
Print Counter Displays the respective counter values in the
master NVM and backup NVM. (read only)
Clear All NVM Initializes the NVM of the Image Processor
Board.
Clear Job Log Initializes the print job history.
Apply New Settings This button should be clicked to move to any
other setting menu from the current menu in
operation.
NOTE After completion of all operations the Restart
printer to apply new settings button should be
clicked without exceptions.
Restart printer to apply new
settings
Click this button when ready to apply your
changes to the settings.
The restart of a printer is required in order to
confirm this setup.
Item Range Parameter Function
Registration -94 ~ 94 Regi Lead Offset Value of Lead Offset
-68 ~ 68 Regi Side Offset Value of Side Offset
Machine - Total PV Counter of Total PV
- FC PV Counter of FC PV
- DEVE Round time K Counter of DEVE Round time
- XERO Round time Counter of XERO Round time
- K Dispense Time Counter of Dispense Time
- K Pixel Counter of K Pixel
- Sheets of Custom Mode Start Counter of Sheets of Custom Mode Start
- Sheets of Custom Mode End Counter of Sheets of Custom Mode End
Toner - K Toner PV Counter of Total P V
- K Toner Pixel Counter of Toner Pixel
- Life K Toner Dispense Time Counter of Toner Dispense Time
- Life K Toner Waste toner count Counter of Toner Waste toner count
