Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 5-3
Parts Lists
Using the Parts List
• ID No.: The callout number from the exploded part diagram.
• Name/Description: The name of the part to be ordered and the number of
parts supplied per order.
• Part Number: The material part number used to order that specific part.
• Parts identified throughout this manual are referenced PL#.#.#; For example,
PL3.1.10 means the part is item 10 of Parts List 3.1.
• A Black triangle preceding a number followed by a parenthetical statement in
an illustrated parts list means the item is a parent assembly, made up of the
individual parts called out in parentheses.
•The notation “with X~Y” following a part name indicates an assembly that is
made up of components X through Y. For example, “1 (with 2~4)” means part
1 consists of part 2, part 3, and part 4.
•The notation “J1<>J2 and P2” is attached to a wire harness. It indicates that
connector Jack 1 is attached to one end of the wire harness and connector J2
is attached to the other end that is plugged into P2.
Note
Only parts with part numbers are available for ordering. Parts without part
numbers are available on the parent assembly.
