Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 1-23
General Information
Memory Specifications
Electrical Specifications
Auto Reduction/
Enlarge (Auto Fit)
On/Off (same as printer driver)
Rotation On/Off (same as printer driver)
N-Up 1/ 2/ 4/ 8/ 16/ 32 (same as printer driver)
Watermark Supported (same as printer driver)
Phone Book Up to 500 Speed Dial numbers and up to 500 Group Dial.
Local phone book stored on PC not linked device.
Characteristic Specifications
Memory 3010/3040 64 MB on board
3045B/N 128 MB on board
Characteristic 3010/3040 3045B/N
Power Supply Voltage/Frequency
Line Voltages 110-127 VAC ± 10% 110-127 VAC ± 10%
220-240 VAC ± 10% 220-240 VAC ± 10%
Frequency Range 50/60 Hz ± 3 Hz 50/60 Hz ± 3 Hz
Current Capacity 110 V Engine: < 8 A
220 V Engine: < 4 A
110 V Engine: < 8 A
220 V Engine: < 4 A
Power Consumption (with all options, 110 or 220 V)
Deep Sleep 2.5 W or less 2.5 W or less
Power Saver Mode 8 W or less 8 W or less
Standby Mode (Fuser On) 37 W or less 37 W or less
Continuous Printing 310W or less 310W or less
Fax Specifications (continued)
Characteristic Specifications
