Xerox WorkCentre 3045B [289/430] Registration roller
![Xerox WorkCentre 3045B [289/430] Registration roller](/views2/1228085/page289/bg121.png)
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 4-79
Service Parts Disassembly
Registration Roller
PL2.3.1
Caution
The gears of the Main Drive Assembly are not captive to the cover. Use care
when removing the cover to maintain the correct gear orientation.
1. Remove the Main Tray (page 4-58).
2. Remove the Front Cover (page 4-60).
3. Remove the Inner Front Cover (page 4-62).
4. Remove the Left Cover (page 4-64).
5. Remove the Right Cover (page 4-57).
6. Remove the Scanner (page 4-109).
7. Disconnect P/J7601 from the Front USB Board.
8. Disconnect P/J6501 from the WiFi Adaptor.
9. Remove the Top Cover (page 4-52).
10. Remove the Rear Cover (page 4-56).
11. Remove the IP Board (page 4-103).
12. Remove the Fax Board if present (page 4-105).
13. Remove the IP Board Bracket (page 4-106).
14. Remove the Main Drive Assembly ().
15. Remove the LVPS (page 4-48).
16. Remove the LVPS bracket (page 4-107).
17. Remove the registration pinch roller (page 4-77).
18. Remove the registration gear, clutch and spring from the Registration Roller
shaft.
