Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 7-5
Wiring
WorkCentre 3045 Plug/Jack Designators
WorkCentre 3045 Plug/Jack Designators
P/J Map Coordinates Description
1 2 H-143 IP Board‚ Harness LV MCES
2 2 E-143 IP Board‚ Harness FAX
5 2 D-141 IP Board‚ Scanner Assy
6 2 E-141 IP Board‚ Scanner Assy
8 2 H-142 IP Board‚ FFC ASSY MC ES
9 2 G-142 IP Board‚ CABLE FFC
10 2 C-122 MCU Board‚ Feed Soleniod
11 2 E-143 IP Board‚ Harness USB FRONT
12 2 E-142 IP Board‚ Harness WIFI
13 2 C-122 MCU Board‚ FFC ASSY MAIN MOT
14 2 C-121 MCU Board‚ Harness LV MC
15 2 C-121 MCU Board‚Harness DISP MOT
16 2 D-121 MCU Board‚FFC ASSY MC HV
17 2 D-121 MCU Board‚FFC ASSY MC ES
18 2 E-122 MCU Board‚ Fuser
18 2 G-144 IP Board‚ Scanner Assy
19 2 G-144 IP Board‚ Scanner Assy
20 2 E-122 MCU Board‚ Harness LV MC
20 2 D-143 IP Board‚ Scanner Assy
21 2 E-123 MCU Board‚ Harness DCRA
21 2 E-143 IP Board‚ Scanner Assy
22 2 E-123 MCU Board‚ ATC Sensor
22 2 F-143 IP Board‚ Scanner Assy
23 2 C-123 MCU Board‚ Registration Sensor Harness
23 2 E-143 IP Board‚Scanner Assy
24 2 C-123
25 2 E-121 MCU Board‚ Harness MC LP
30 1 F-108 LPH‚ CABLE FFC
102 3 C-138 Fax Board‚ Harness FAX
130 1 B-108 Main Drive Motor‚ FFC ASSY MAIN MOT
150 2 E-122 Toner Motor‚ Harness DISP MO
160 2 B-127 HVPS‚ FFC ASSY MC HV
200 2 I-123 Power Switch Assembly‚ LVPS
201 2 I-123 Fuser‚ LVPS
202 2 H-124 LVPS‚Harness LV MC
203 2 H-123 LVPS‚Harness LV MC
204 2 H-124 LVPS‚ Rear Door Interlock Switch
205 2 G-123
230 1 E-109 Registration Sensor‚ Registration Sensor Harness
911 2 H-142 IP Board‚ Harness MC LP
6601 3 E-135 WiFi Bracket Assembly‚ Harness WiFi
7601 3 I-136 Front USB Board‚ Harness USB Front
