Xerox WorkCentre 3045B [164/430] Applicable error
![Xerox WorkCentre 3045B [164/430] Applicable error](/views2/1228085/page164/bga4.png)
2-110 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
K CRU Detached
An unsupported Toner Cartridge is detected, or a No Toner Cartridge Installed
state was detected.
Applicable Error
• 093-974: X CRU Detached
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Toner Cartridge, PL4.1.5
■ MCU Board, PL7.2.2
■ “Map 2” on page 4
■ “Toner Dispense” on page 17
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Toner Cartridge.
Does the error persist?
Go to Step 2. Complete.
2 Check P/J21 on the MCU Board.
Is the connector secure?
Go to Step 4. Secure P/J21.
3 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance.
Complete.
