Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-63
Error Troubleshooting
Download Errors
The system firmware file is corrupt or communications to the printer failed.
Applicable Error
• 016-737: Download ID Error
• 016-741: Download Range Error
• 016-742: Download header Error
• 016-743: Download Checksum Error
• 016-744: Download Format Error
• 016-745: Download Protect Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.2.8 (3010/3040)
■ IP Board, PL7.3.3 (3045)
■ MCU Board, PL7.1.3
■ “Map 3 - IP Board” on page 7-8
■ “IP Board” on page 7-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat all connectors on the IP and
MCU Boards.
Does the error persist?
Go to Step 2. Complete.
2 Replace the IP Board (page 4-45).
Does the error persist?
Go to Step 3. Complete.
3 Replace the MCU Board (page 4-43).
Does the error persist?
Contact your
designated
field support for
assistance
Complete.
