Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 2-101
Error Troubleshooting
Exit Off Early Jam
The paper passed through the Exit Sensor earlier than the specified time, or did
not pass through the Exit Sensor within the specified time.
Warning
Allow the Fuser to cool before servicing the printer.
Applicable Errors
• 077-108: Exit Off Early Jam
• 077-109: Exit Off Jam
Initial Actions
• Check the media path for obstructions or debris.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser, PL5.1.1
■ MCU Board, PL7.1.3
■ “Map 2” on page 7-4
■ “Fuser” on page 7-18
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check P/J18 on the MCU Board.
Is P/J18 connected securely.
Go to Step 2. Secure P/J18.
2 Replace the Fuser (page 4-38).
Does the error persist?
Replace the
MCU Board
(page 4-43).
Complete.
