7-2 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Wiring
Printer Plug/Jack Designations
This chapter contains the plug/jack designators, locator diagrams, and wiring
diagrams. The Plug/Jack Locator diagrams show the P/J locations within the
printer. Use these illustrations to locate connections called out in the
troubleshooting procedures.
1. Locate the P/J connector designator in the first column of the table.
2. With this information, go to the map listed in the Map column.
3. Use the coordinates to locate the connection indicated on the map by its P/J
designation number.
4. The Remarks column provides a brief description of each connection.
Phaser 3010/3045 Plug/Jack Designators
Phaser 3010/3040 Plug and Jack Designators
P/J Map Coordinates Remarks
1 2 H-122 IP Board‚ Harness LV MCES (PL7.1.9)
8 2 H-121 IP Board‚ FFC MC ES
9 2 I-121 IP Board‚ CABLE FFC
10 2 C-121 MCU Board‚ Feed Solenoid
13 2 C-121 MCU Board‚ FFC MAIN MOT
14 2 C-120 MCU Board‚ Harness LV MC
15 2 C-120 MCU Board‚ Harness DISP MOT
16 2 D-120 MCU Board‚ FFC MC HV
17 2 D-120 MCU Board‚ FFC MC ES
18 2 E-121 MCU Board‚ FUSING
20 2 E-121 MCU Board‚ Harness LV MC
21 2 E-122 MCU Board‚ Harness DCRA
22 2 E-122 MCU Board‚ ATC Sensor
23 2 C-122 MCU Board‚ Registration Sensor Harness
24 2 C-122
25 2 E-120 MCU Board‚ Harness MC LP
30 1 F-106 LPH‚ CABLE FFC
130 1 B-106 Main Drive Motor‚ FFC ASSY MAIN MOT
150 2 E-121 Toner Motor‚ Harness DISP MOT
160 2 B-126 HVPS‚ FFC MC HV
200 2 I-122 Power Switch Assembly‚ LVPS
201 2 I-122 Fuser‚ LVPS
202 2 H-124 LVPS‚ Harness LV MC (PL7.1.8)
203 2 H-123 LVPS‚ Harness LV MC (PL7.1.8)
204 2 H-124 LVPS‚ Rear Door Interlock Switch
205 2 G-123
230 1 E-107 Registration Sensor‚ Registration Sensor Harness
250 2 H-122 IP Board‚ Harness MC LP
