1-26 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
General Information
Physical Dimensions and Clearances
3010/3040 Dimensions
3045B Dimensions
3045N Dimensions
Characteristic Measurement
Height 208 mm ( 8.2 in.)
Width 358 mm ( 14.1 in.)
Depth 197 mm ( 7.8 in.)
Weight (base printer with consumables) 4.6 kg (10.0 lb.)
Characteristic Measurement
Height 584 mm (23 in)
Height with 250-Sheet Feeder 690 mm (27.1 in.)
Width 430 mm (16.9 in.)
Depth 544 mm (21.4 in.)
Weight (base printer with consumables) 28.8 kg (63.5 lb.)
Characteristic Measurement
Height 584 mm (23 in)
Height with 250-Sheet Feeder 690 mm (27.1 in.)
Width 430 mm (16.9 in.)
Depth 544 mm (21.4 in.)
Weight (base printer with consumables) 28.8 kg (63.5 lb.)
