Xerox WorkCentre 3045B [64/430] Phaser 3010 3040 error codes
![Xerox WorkCentre 3045B [64/430] Phaser 3010 3040 error codes](/views2/1228085/page64/bg40.png)
2-10 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service
Error Troubleshooting
Phaser 3010/3040 Error Codes
The Phaser 3010/3040 Error Message Summary table lists possible errors, along
with the corresponding code, and page reference for the corrective procedure.
• The Code column lists the code associated with the error.
• The Error Message column shows the error history message when the error
occurs during normal operation.
• The Error Description column describes the error.
• The Go to column links to the troubleshooting procedure related to the error.
Use this table to identify the proper procedure to correct the reported error.
Phaser 3010/3040 Error Message Summary
Code Error Message Error Description Go to page
010 397 010-397
Restart Printer
Contact Support
If Message Returns
Fusing Failure
Fusing temperature
anomaly detected.
2-56
016 315 016-315
Restart Printer
Contact Support
If Message Returns
DRAM check failure
DRAM check error
occurred
Install new
firmware. If the
error persists, go to
page 2-57.
016 317 016-317
Restart Printer
Contact Support
If Message Returns
ROM content invalid
Invalid ROM content
detected.
Install new
firmware. If the
error persists, go to
page 2-57.
016 501 016-501
Write Flash Error
Contact Support
If Message Returns
Write Flash Error
Can not update
application code in
FLASH
Install new
firmware. If the
error persists, go to
page 2-59.
016 502 016-502
Write Flash Error
Contact Support
If Message Returns
Write Flash Error
Can not update
parameters in FLASH
Install new
firmware. If the
error persists, go to
page 2-59
016 718 016-718
Memory Full
Job Failure
Press Ok
Memory Over flow
The current job
exceeds memory
capacity.
Reduce print job
size. If the error
persists, go to
page 2-61
016 719 016-719
Decode Error
Job Failure
Press Stop to Cancel
Decode error
Decode error is
detected.
Try printing again.
If the error persists,
go to page 2-62
016 720 016-720
PDL Request
Data Violation
Press Ok
PDL Error
The print data cannot
be processed by PDL
Check USB or
network cable
connection. If the
error persists, go to
page 2-64.
