- 81 -

 Trigger recording by motion detection

When the motion detection function of the selected camera is

enabled, you can configure the camera to start recording triggered

by the motion detected. Click SETTING > Motion Configuration,

and then select the Recording option to enable the selected

camera to record by motion detection.
