Asus WS X299 PRO/SE [16/142] Package contents

xvi

Package contents

Check your motherboard package for the following items.

Motherboard 1 x WS X299 PRO Series motherboard

Cables

6 x Serial ATA 6Gb/s cables

1 x VGA bracket cable (for WS X299 PRO/SE only)

1 X USB 2.0 bracket cable

1 X Addressable cable

Accessories

2 x M.2 screws kits

1 x ASUS 3-Way SLI™ bridge

1 x ASUS SLI™ bridge

1 x COM port brackets

1 X I/O shield

1 X ASUS fan holder

1 X 40mm x 40mm fan kit

Application DVD 1 x Motherboard support DVD

Documentation 1 x User guide

If any of the above items is damaged or missing, contact your retailer.
