Asus WS X299 PRO/SE [42/142] Chapter 1

1-24

Chapter 1: Product Introduction

Chapter 1

1. Message LED (2-pin MLED)

This2-pinconnectorisforthemessageLEDcablethatconnectstothefrontmessage

LED.ThemessageLEDiscontrolledbytheBMCtoindicateanabnormalevent

occurrence.

Thisconnectormaybedisableddependingonthemodel.

10. System panel connector (20-1 pin PANEL1)

(for WS X299 PRO/SE only)

Thisconnectorsupportsseveralchassis-mountedfunctions.
