Asus WS X299 PRO/SE [81/142] Qfan control for ws x299 pro only

ASUS WS X299 PRO Series

3-7

Chapter 3

3.2.3 QFan Control (for WS X299 PRO only)

The QFan Control allows you to set a fan prole or manually congure the operating speed of

your CPU and chassis fans.

Click to select a fan to be

congured

Click to undo the

changes

Click to apply the fan setting

Click to go back to main menu

Select a prole to apply to

your fans

Click to activate DC Mode

Select to manually congure

your fans
