3-20

Chapter 3: BIOS Setup

Chapter 3

3.6.12 Thunderbolt(TM) Conguration

The items in this menu allow you to congure Thunderbolt settings.

TBT Root port Selector

This item allows you to select the thunder root port.

Conguration options: [Thunderbolt Disabled] [PCIE16_1] [PCIE16_2] [PCIE4_1]

3.6.13 PCH-FW Conguration

This item allows you to congure the rmware TPM.

3.7 Monitor menu (for WS X299 PRO only)

The Monitor menu displays the system temperature/power status, and allows you to change

the fan settings.

Qfan Conguration

Qfan Tuning

Click this item to automatically detect the lowest speed and congure the minimum

duty cycle for each fan.

AIO PUMP/W_PUMP+ Control

[Disabled] Disable the Water Pump control feature.

[Auto] Detects the type of water pump installed and automatically switches

the control modes.

[DC mode] Enable the Water Pump control in DC mode for 3-pin chassis fan.

[PWM mode] Enable the Water Pump control in PWM mode for 4-pin chassis fan.
